RFM05N23 Long Distance Laser Rangefinder

Item No.: RF05N
* Powerful laser module for extended range finding
* Fit for long distance monitoring and surveillance
* 8° extra wide Field of View offers pleasant observation
get a free quote

OVERVIEW

NUTREK RFM05N23 Series Laser Rangefinders are an indispensable aid for long-distance shooting, as well as surveillance, forestry management, etc.

* Using high power and precision laser components that measure long distances up to 2300m with accuracy within 1M

* Multiple Mode including measuring in rainy weather

* Switch between yard or meter for distance unit

* Fit for military, hunting, sniper, surveillance, etc








SPECS

ITEM# RFM05N23
MODEL 2.3KM Long Distance Laser Rangefinder
Distance Measurement Range 5-2300m
Distance Measurement Deviation ±1m±0.1%
Distance Measurement Unit Yard / Meter
Pin Seeker Range 5-300m
Field of Fiew 8°
Magnification 7X
Objective Diameter 25MM
Exit Pupil Diameter 3.6MM
Eye Relief 13.5MM
Foggy Mode YES
Height Measure Optional
Angle Measure Optional
Scan Mode YES
Golf Mode / Pin Seeking Optional
Laser Safety FDA Class I (CFR 21), Eye-safe
Laser Wave Length 905 nm
Display LCD
Ingress Protection Level IP54
Auto Power Shutoff 30 sec.
Battery Type 6F22-9V Lithium
Work Duration Approx 10,000 measurements
Product Size 53×127×125x53mm
Weight (W/O battery) 440g
Certifications FCC,FDA,CE,RoHs

FEATURES

  • Color

    Matte black by default
    Other colors can be customized

SPECIFICATION

ITEM# RFM05N23
MODEL 2.3KM Long Distance Laser Rangefinder
Distance Measurement Range 5-2300m
Distance Measurement Deviation ±1m±0.1%
Distance Measurement Unit Yard / Meter
Pin Seeker Range 5-300m
Field of Fiew 8°
Magnification 7X
Objective Diameter 25MM
Exit Pupil Diameter 3.6MM
Eye Relief 13.5MM
Foggy Mode YES
Height Measure Optional
Angle Measure Optional
Scan Mode YES
Golf Mode / Pin Seeking Optional
Laser Safety FDA Class I (CFR 21), Eye-safe
Laser Wave Length 905 nm
Display LCD
Ingress Protection Level IP54
Auto Power Shutoff 30 sec.
Battery Type 6F22-9V Lithium
Work Duration Approx 10,000 measurements
Product Size 53×127×125x53mm
Weight (W/O battery) 440g
Certifications FCC,FDA,CE,RoHs
