OVERVIEW
Advanced "Christmas Tree" Holdover Reticle: The RS1406S reticle features a sophisticated windage and elevation grid beneath the center crosshair. Shooters can execute instantaneous holdovers for wind drift and bullet drop entirely through the glass, eliminating the need to break cheek weld to dial turrets.
24x High-Magnification Clarity: Paired with a 50mm FMC objective lens, the high-magnification range provides crisp resolution at extreme distances, allowing effortless target identification, impact tracking, and mirage assessment.
Crisp 0.1 MRAD Tactile Adjustments: Precision-engineered turrets deliver distinctive audible and tactile clicks for exact tracking, ensuring that every click translates reliably to the target grid.
Elite Parallax & Zero-Stop Integration: Side focus parallax controls optical errors from 10 yards out to infinity, working alongside the Zero-Stop mechanism to offer an uncompromised competitive edge in long-range shooting disciplines.
SPECIFICATION
| ITEM# | RS1402S | RS1404S | RS1406S | RS1417S | |
| MODEL | 2.5-10x50 | 4-16x44 | 6-24x50 | 3-18x50 | |
| TUBE SIZE | 30mm | ||||
| POWER RATIO | 4x | 4x | 4x | 6x | |
| CLICK VALUE | 0.1 MRAD | ||||
| RETICLE | FOCAL PLANE | SFP | |||
| ILLUMINATION | Yes | ||||
| TYPE | Etched Glass | ||||
| FIELD OF VIEW | ft@100yds | 42.5-12.6 | 24.6-6.3 | 18.3-4.6 | 38.2-6.2 |
| m@100m | 14.2-4.2 | 8.2-2.1 | 6.1-1.53 | 12.7-2.1 | |
| W/E ADJUSTMENT RANGE | ±14.5/±14.5 MIL | ±10.2/±10.2 MIL | ±7.3/±7.3 MIL | ±18.9/±18.9 MIL | |
| FOCUS SETTING | 100yds | 10yds~∞ | 10yds~∞ | 10yds~∞ | |
| EYE RELIEF (MM) | 105-100 | 105-100 | 105-100 | 96-95 | |
| TURRET STYLE | TAC-LOK | ZERO-STOP | ZERO-STOP | ZERO-STOP | |
| COATING | FMC | ||||
| WEIGHT (G) | 690 | 712 | 752 | 789 | |
| LENGTH (MM) | 326 | 356 | 369 | 359 | |
