OVERVIEW
Advanced 6x Optical Zoom Ratio: Provides ultimate versatility across all terrains. Move seamlessly from a wide-field 3x magnification for close-quarters tracking or dense timber up to an intense 18x magnification for high-precision, long-range extractions.
Massive ±18.9 MIL W/E Tracking Budget: Engineered with an expanded ±18.9 MIL internal adjustment travel. This generous elevation and windage capacity allows shooters using popular long-range calibers (such as 6.5 Creedmoor or .300 Win Mag) to dial confidently for extreme bullet drops at extended distances.
Heavy Recoil-Ready Chassis (1000G Rated): The ruggedized 30mm aircraft-grade aluminum single-piece tube is rated to withstand 1000G of shock force, guaranteeing zero shift and long-term durability on hard-hitting, large-caliber rifle platforms.
Optimized Eyebox for Operator Safety: Featuring a comfortable 96-95mm eye relief, the optical system creates a forgiving eyebox that speeds up target acquisition and keeps the shooter’s brow safely clear of heavy caliber recoil.
SPECIFICATION
| ITEM# | RS1402S | RS1404S | RS1406S | RS1417S | |
| MODEL | 2.5-10x50 | 4-16x44 | 6-24x50 | 3-18x50 | |
| TUBE SIZE | 30mm | ||||
| POWER RATIO | 4x | 4x | 4x | 6x | |
| CLICK VALUE | 0.1 MRAD | ||||
| RETICLE | FOCAL PLANE | SFP | |||
| ILLUMINATION | Yes | ||||
| TYPE | Etched Glass | ||||
| FIELD OF VIEW | ft@100yds | 42.5-12.6 | 24.6-6.3 | 18.3-4.6 | 38.2-6.2 |
| m@100m | 14.2-4.2 | 8.2-2.1 | 6.1-1.53 | 12.7-2.1 | |
| W/E ADJUSTMENT RANGE | ±14.5/±14.5 MIL | ±10.2/±10.2 MIL | ±7.3/±7.3 MIL | ±18.9/±18.9 MIL | |
| FOCUS SETTING | 100yds | 10yds~∞ | 10yds~∞ | 10yds~∞ | |
| EYE RELIEF (MM) | 105-100 | 105-100 | 105-100 | 96-95 | |
| TURRET STYLE | TAC-LOK | ZERO-STOP | ZERO-STOP | ZERO-STOP | |
| COATING | FMC | ||||
| WEIGHT (G) | 690 | 712 | 752 | 789 | |
| LENGTH (MM) | 326 | 356 | 369 | 359 | |
